| Application Zone | : | Outdoor |
| Application | : | Outdoor Reference Air |
| Brand | : | Veris |
| Dimension Depth | : | 2.12" (54 mm) |
| Dimension Height | : | 4" (102 mm) |
| Dimension Probe Diameter | : | 0.7" (18 mm) |
| Dimension Probe Length | : | 4.73" (102 mm) |
| Dimension Width | : | 4" (102 mm) |
| Electrical Wiring Size | : | 22 AWG (0.32 mm²) |
| Enclosure Material | : | ABS Plastic |
| IP Protection | : | IP65 (NEMA 4) |
| Measurement Type | : | Temperature |
| Model | : | TOAM10 |
| Mounting | : | Outdoor |
| Operating Temperature | : | -13 - 221 °F (-25 - 105 °C) |
| Output Specifications | : | 4 - 20 mA |
| Outputs | : | Analog output |
| Product Certification | : | CE |
| Product Type | : | Sensor |
| Range | : | TO |
| Supply Voltage DC Range | : | 12 - 30 VDC |
| Temperature Calibration Certificate | : | None |
| Temperature Measurement Accuracy | : | ±0.9 °F (±0.5 °C) |
| Temperature Measurement Range | : | -40 - 122 °F (-40 - 50 °C) |
| Temperature Sensor Type | : | Temperature Transmitter |
| Warranty | : | 5 years |
TO series outdoor temperature sensors feature a sleek, weather resistant design, and provide easy installation. The durable probe is encased in a radiation shield to reduce the effects of solar heating.
- Sleek design - reduces solar heating, reliable and accurate
- Flexible
- Weather resistant junction box
- 2-wire, loop powered Class 2 temperature output
- Solid-state, integrated circuit sensor
