Veris TAHJ0 Averaging Temperature Sensor

Copper Tubing 12 ft 10 kOhm Dale Thermistor NTC Averaging Temperature Sensor

  • Brand Name: Veris
  • Veris Part#: TAHJ0
  • Est. Shipping Date: loading
Temperature Sensor Type      :      10k Ohm Dale Thermistor
Temperature Measurement Accuracy      :      ±0.4 °F (±0.2 °C)
Temperature Calibration Certificate      :      None
Mounting      :      Duct with Mounting Box
Outputs      :      Resistive output
Application      :      Chiller | Heat Exchangers
Application Zone      :      Plant Room
Brand      :      Veris
Dimension Depth      :      1.8" (44 mm)
Dimension Height      :      4.2" (102 mm)
Dimension Probe Diameter      :      3/16" (4.8 mm)
Dimension Width      :      2.3" (58 mm)
Electrical Wiring Size      :      22 AWG (0.32 mm²)
Enclosure Material      :      Galvanized Steel
Measurement Type      :      Temperature
Model      :      TAHJ0
Operating Temperature      :      -13 - 221 °F (-25 - 105 °C)
Product Type      :      Sensor
Range      :      TA
Temperature Measurement Range      :      -4 - 158 °F (-20 - 70 °C)
Warranty      :      5 years

The TA series is a flexible TA sensor which averages the temperature read across the entire length of the copper tubing, making it ideal for duct temperature measurements. TA series sensors average the measured temperature across the duct in 12 ft lengths for the flexible probe.
