Veris U013-0011 Input/Output Module

8-Input Flexible I/O Module

  • Brand Name: Veris
  • Veris Part#: U013-0011
  • Est. Shipping Date: loading
Dimensions      :      3.40" (86 mm) W x 4.20" (106 mm) L x 1.20" (31 mm) H
Number of Devices Supported      :      Analog/Pulse/Resistance: 8 selectable inputs
Operating Temperature      :      0 - 50 deg C
Supply Power      :      24 VDC

The A8332-8F2D input module provides a convenient way to optimize energy use and accurately allocate costs. Add eight standard pulse and/or analog sensors to a data acquisition network. Integrate your Veris network sensors through the A8332-8F2D to a Veris H8822 Data Acquisition Server. The A8332-8F2D is the first truly flexible input module that allows incorporation of virtually any industry-standard sensor through a single device. The module can be incorporated with cost-effective data acquisition and wireless metering solutions such as the H8822 AcquiSuite DR server, which, as a properly integrated system, provides high performance and low cost. This system can be incorporated into a new or existing Building Automation System (BAS). Using the AcquiSuite data acquisition system, users can set input types (pulse, analog, resistive, etc.), giving access to real time resource consumption for a facility on a single board.

  • Connect up to eight industry standard sensors to the AcquiSuite data acquisition network
  • Universal inputs simplify setup, just connect sensors and select device output type via the AcquiSuite or using Obvious configuration software
  • Check device status at a glance, LED indicators allow for fast recognition of on/off status, TX/RX communications, and 8 input notifications
  • Field-selectable address DIP switch, no software or PC configuration required at device
  • High reliability - non-volatile memory retains configuration and pulse data during power failures
  • All configuration information and input data is stored in nonvolatile memory to prevent data loss in the event of power failure
  • 8 input status LEDs (red), 2 Modbus TX/RX (yellow), 1 power/alive status (green) LED
  • 8x, user selectable - 0 to 10 V: min/max/ave/instantaneous; 4 to 20 mA: min/max/ave/instantaneous; pulse: consumption, rate; resistance: 0 to 10 V: min/max/ave/instantaneous inputs
  • RS-485 port is optically isolated isolation
  • Power supply not included
