Veris U013-0010 Input/Output Module

23-Pulse Input Module

  • Brand Name: Veris
  • Veris Part#: U013-0010
  • Est. Shipping Date: loading
Dimensions      :      3.40" (86 mm) W x 4.20" (106 mm) L x 1.20" (31 mm) H
Number of Devices Supported      :      23 independent puce count inputs
Operating Temperature      :      0 - 50 deg C
Supply Power      :      9 - 30 VDC

The A8911-23 input module provides an easy way to integrate multiple pulse output devices to Modbus systems such as the Veris AcquiSuite data acquisition network. The A8911-23 accepts up to 23 standard pulse sensors and can function as a slave device with any Modbus master. This data can be networked to other critical energy sensors such as Veris Modbus power meters to provide a comprehensive energy monitoring solution.

  • External communications via shielded twisted pair 18 to 22 ga wire, allows communication up to 4000 ft
  • Pulse input communication up to 200 ft using 18 to 24 ga control wire
  • DIN rail mounting - quick and easy installation
  • On-board DIP switches for Modbus addressing
  • Industry standard pulse inputs connect to most pulse output meters
  • LED verification of RS-485 Modbus TX/RX communications
  • Pulse inputs, power inputs and RS-485 are non-isolated isolation
  • 23 independent pulse count inputs - 32-bit pulse counter, rolls over at 4.295 billion per channel, intended for use with dry contact outputs
  • 23 independent pulse count inputs - pulse count values stored in nonvolatile memory, pulse rate/width user selectable to 10, 50, or 100 Hz
  • Power supply not included
